02 · DRAWING SET

Configure the DWG package

Select the plane groups and presentation required for this package. Drawing titles are generated from their exact axes and coordinates.

DWG · ZIP

Planes to Include X 0Y 0Z 0 Sloped roof framing is included with Y drawings when detected.

Member Drawing Mode

Draw Members as Polylines Draw Members at True Depth

Drawing Controls Presentation · Content · Plane Detection

Member Sizes PresentationChoose how member sizes are identified, or create a clean drawing with no annotations. Polyline Width mmDefault centreline member width · 50 mm

Dimensions

Layer Organisation Plane Tolerance mm Minimum Members / Plane

Outside FlushKeeps the outside face continuous through connected members.

Draw Flange ThicknessShows the flange-to-web boundaries in web-side views.

Draw Web ThicknessShows the centred web faces as hidden lines in flange-side views.

Primary Frame DirectionSmart Auto respects the selected plane and BETA orientation.

Text Settings Paper Sizes · Scaled Automatically

Enter the final printed size. The drawing engine multiplies it by each drawing’s A1 plot scale.

Printed Text Height mmUse 0 to omit general drawing text. Printed Title Height mmUse 0 to omit the main drawing title. Text Width Factor Text Font Oblique Angle ° Member Text Clearance × Text HeightDefault 0.5 · measured from the polyline edge or actual true-depth outline. Wrap After Characters Leader Arrow HeadAvailable with Text with Leaders.

Dimension Settings Dimensions OFF

Dimension Units Precision Arrow Head Printed Text Height mm Printed Arrow Size mm Printed Dimension Offset mm Printed Extension Gap mm

Print-ready model spaceAll geometry is exported in millimetres at 1:1. The A1 border expands to the calculated plot scale and the saved view opens on the complete sheet.

After changing any drawing setting, refresh the drawings before review or export.

Every structural plane.
One clean DWG package.

Choose your STAAD STD or ANL file

Configure the DWG package

Review the output drawings
